Performance
|
Printing Method |
Thermal Line |
| Printing Speed |
62mm/s |
| Resolution |
8 dots/mm; 384 dots/line |
| Effective Printing Width |
48mm |
| Paper Width |
57.5± 0.5mm |
Printing support
|
Chinese |
GB three characters: 16 × 16 dot matrix, 24× 24 dot matrix |
| Western |
ASCII: 8x16 dot matrix, 9 × 24 dot matrix, 12× 24 dot matrix |
| Custom characters |
support |
| Graphical printing |
Support different density dot graph anddownload graphic print |
Barcode
|
1D: UPC-A;UPC-E;EAN-13;EAN-8;CODE39; |
| 2D: PDF417；QRCODE；DATAMATRIX |
Paper Specification
|
Paper Type |
General Thermal paper |
| Paper Width |
57.5± 0.5mm |
| Paper Thickness |
0.06~0.08mm |
| Paper Supply Method |
Drop-in easy paper loading |
| Paper Cutting Method |
Manual tearing |
| Paper Roll Diameter |
40mm (Max) |
| Interface |
USB /RS-232/ Bluetooth |
| Support function |
out of paper alarm,
overheating protection,
black mark positioning,
automatic sleep,
the battery power alarm |
Power supply
|
Battery:1500mAh |
| Charger External power supply printing is not supported |
Physical properties
|
Physical dimension:106.5mmx78mmx47mm（LxWxH） |
| Weight:190g（No paper rolls） |
Environment
|
Operating Temperature/ Humidity: 0～50℃/10～80% |
| Storage Temperature/ Humidity: /10～80%/10～90% |
| Life/Reliability |
Printer head life: 50km |
| SDK |
Windows CE; Windows Mobile 5.0/6.0; Symbian; Blackberry and Android;
Support IOS, and conformance with MFI certificate |
